Ingersoll-Rand 6” x 6” Stroke 1925psi Cylinder SN: 6HC3380

Cylinder 4

Type: HOS

Bore: 6"  152.4 mm

Stroke: 6"  152.4 mm

RDP: 1750  123.1 kg/cm2g

MAWP: 1925  135.4 kg/cm2g

HTP: 2890  203.2 kg/cm2g

MADGT: 350 F  177 C

RPM: 1200

Base Cylinder Clearance

Outer End: 24.8

Frame End: 30.0

Normal Lineal Clearance

.09" 2.4mm

.06" 1.6mm

SN: 6HC3380
