Ariel JGE-4 SN: F-19244/ Cat G3516TALE Three Stage Compressor Size 15.25" x 15.25" x 9.75" x 6"

Ariel JGE-4 SN: F-19244/ Cat G3516TALE Three Stage Compressor Size 15.25" x 15.25" x 9.75" x 6"

or
Call 661-257-8000

Description

Cylinders



Ariel 1st Stage Cylinders

Bore: 15.25”

Stroke: 4.5”

Class: ET

MAWP: 200

SN: C-60615

SN: C-60614

Complete with VVCP



Ariel 2nd Stage Cylinder

Bore: 9.75”

Stroke: 4.5”

Class: ET

MAWP: 635

SN: C-60616

Complete with VVCP



Ariel 3rd Stage Cylinder

Bore: 6”

Stroke: 4.5”

Class: ET

MAWP: 1270

SN: C-47025



Air X Changer

Model: 144EH

3 Stage plus EJW

Cooling Sections: 150, 645, 645, 1440 @ 250 Deg F

Job #: 031175


Unit parameters



  1. Suction: 20-63 psi
  2. Discharge: 1st 80-200psi, 2nd 120-500psi, 3rd 300-1250.
  3. Volume: 3.8 - 5.1 MMSCFD



Specifications

ManufacturerAriel
ModelJGE-4
Year2003
ConditionUsed
Serial NumberF-19244
Stock NumberCS-0019875
ModelJGE-4
Stroke4.5”
RPM1500
Cylinder Sizes15.25 x 15.25 x 9.75 x 6
Driver ModelG3516SITALE
Driver MFGCAT
MFG2003
Rod Load62,000
Engine SN4EK02789
# of stages3
Driver RPM1400
Compression Ratio8.1
Arrng #105-4176
Driver HP1265
