Flex Energy/ Ingersoll Rand MT250 Micro Turbine Natural Gas Generator SN: 00054

FLEX ENERGY / INGERSOLL RAND MT250 MICRO TURBINE AND LOAD BANK

Flex Energy Flex Turbine

Model: MT250

M.C. Watteuw N.V.

Kampveldstraat 51

B-8020 Oostkamp

Belgium

Application: IR-60-CO

Assembly PN: 46390464

SN: 00054

Rating: 250 KW

Input Speed: 45390 RPM

Ratio: 25.22

Output Speed: 1800 RPM

Lubricant: IR Megacool

Viscosity: ISO VG32

Oil Pressure: 2.4 bar

Oil Temperature: max 92 deg C

Date: 12-2008

Marathon Electric Generator End

Magnamax DVR

Synchronous AC Generator

Model: 433RDL4851

Type: RDL

S/N: WA-572700-0310

Hz: 60 / 50

RPM: 1800 / 1500

Phase: 3

Volts: 480Y/277 / 400Y/230

Ins Class: H1

PMG Volts: 190 / 150

PMG Hertz: 300 / 250

Continuous Duty 60 Hz

KW: 340 Kva: 425 Amps: 511 Ambient 40 deg C rise by resistance 95 deg C

Exciter Field Amps DC 1.7 Exciter Field Volts DC: 40

KW: 200 Kva: 250 Amps: 301 Ambient 60 deg C rise by resistance 73 deg C

Exciter Field Amps DC 1.2 Exciter Field Volts DC: 34

Continuous Duty 50 Hz

KW: 300 Kva: 375 Amps: 541 Ambient 40 deg C rise by resistance 105 deg C

Exciter Field Amps DC 2.4 Exciter Field Volts DC: 55

KW: 200 Kva: 250 Amps: 360 Ambient 60 deg C rise by resistance 70 deg C

Exciter Field Amps DC 2.0 Exciter Field Volts DC: 46

KW: 340 Kva: 375 Amps: 541 Ambient -7 deg C rise by resistance 150 deg C

Exciter Field Amps DC 2.4 Exciter Field Volts DC: 55

IR Energy Systems

Powerworks recouperator

PN: 51000506

SN: 4-000162

Max operating pressure: 472 kpa (ABS)

Operating Temperature: 650 deg C

Simplex Forced Air Cooled Resistive Load Bank

Model: Neptune 240

Capacity: 240 KW at 1.0 PF

Cooling: Forced Air

Airflow: 11,500 CFM

Max air intake: 120 deg F

Nominal air temperature rise: 90 deg F – 500 deg F max

Temp rise: kw x 3000 / cfm

Duty Cycle: Continuous 5 kva

Load/Control Power Circuit:

Voltage: 480 VAC

Connection: 3 phase 3 wire

Fan power: internal 489 VAC

Control power: internal 480:120V Transformer

Full load amps: 295A

Fan motor current: 4.8A

Environmental Type: 3R

SN: 80127-12-43/10
